运行环境：泛微E9，ecode版本为1.9.14

实现效果：在流程界面，依流程名称/流程节点，获取各个节点的配置说明内容，如下：

第一步：建模建表如下，生成API接口（略），供调用，

第二步：创建ECODE项目（在流程界面组件用滑块）

2.1 ecode建好项目（按标准ecode提供的案例）

2.2 这些文件上做好设置

2.3各代码的具体代码：

样式：index.css

.wea-new-top-req-content{font-size:14px;color:rgb(61,126,247);font-weight: 400;}

配置：config.js

const configs={
 wfids:[535, 1645, ], //多个流程id逗号隔开
};
ecodeSDK.setCom("${appId}","configs",configs);

配置要加载的页面：register.js

const configs = ecodeSDK.getCom('${appId}', 'configs')//获取对应的appid
let isRun = true;
ecodeSDK.overwritePropsFnQueueMapSet('WeaReqTop', {
  fn: (newProps) => {
    const { hash } = window.location//获取当前页面的URL
    if (!~hash.indexOf('/main/workflow/req')) return newProps;
    if (!window.wfform) return newProps;
    let baseInfo = wfform.getBaseInfo() // 获取流程基础信息（包含workflowid、jdid等）


    if (!configs.wfids.includes(Number(baseInfo.workflowid))) return newProps;


    if (isRun) {
      let timer1 = setTimeout(() => {
        if ($('.wea-new-top-req-content').length > 0) {
          $('.wea-new-top-req-content').prepend('<div id="wfRightInfo"></div>');
          const acParams = {
            appId: 'ac6865876e5e4ea9ab2e2880894f18de',
            name: 'WfCustomInfoCopy',
            // 传递流程基础信息作为组件参数（供接口调用使用）
            params: {
              workflowid: baseInfo.workflowid,
              // jdid: baseInfo.nodeid, // 假设baseInfo包含jdid（流程实例ID）
              // lc: baseInfo.workflowid,     // 假设baseInfo包含（流程节点相关）
              operator: baseInfo.creatorid // 假设使用创建者ID作为操作人
            },
            isPage: false,
            noCss: true,
          }

          ReactDOM.render(ecodeSDK.getAsyncCom(acParams), document.getElementById('wfRightInfo'))
          clearTimeout(timer1)
        }
      }, 10);
      isRun = false;
    }
    return newProps;
  }
})

加载的页面内容:index.js

const { WeaTools, WeaSlideModal } = ecCom;
const { callApi } = WeaTools;

class WfCustomInfoCopy extends React.Component {
  constructor(props) {
    super(props);
    this.state = {
      visible: true,
      data: null, // 接口返回数据
      loading: true, // 加载状态
      error: null // 错误信息
    };
  }

  componentDidMount() {
    // 组件挂载后调用接口
    this.executeRequest();
  }

  // MD5加密工具函数（保持不变）
  md5(string) {
    function rotateLeft(lValue, iShiftBits) {
      return (lValue << iShiftBits) | (lValue >>> (32 - iShiftBits));
    }

    function addUnsigned(lX, lY) {
      let lX4, lY4, lX8, lY8, lResult;
      lX8 = (lX & 0x80000000);
      lY8 = (lY & 0x80000000);
      lX4 = (lX & 0x40000000);
      lY4 = (lY & 0x40000000);
      lResult = (lX & 0x3FFFFFFF) + (lY & 0x3FFFFFFF);
      if (lX4 & lY4) return (lResult ^ 0x80000000 ^ lX8 ^ lY8);
      if (lX4 | lY4) {
        if (lResult & 0x40000000) return (lResult ^ 0xC0000000 ^ lX8 ^ lY8);
        else return (lResult ^ 0x40000000 ^ lX8 ^ lY8);
      } else return (lResult ^ lX8 ^ lY8);
    }

    function F(x, y, z) { return (x & y) | ((~x) & z); }
    function G(x, y, z) { return (x & z) | (y & (~z)); }
    function H(x, y, z) { return (x ^ y ^ z); }
    function I(x, y, z) { return (y ^ (x | (~z))); }

    function FF(a, b, c, d, x, s, ac) {
      a = addUnsigned(a, addUnsigned(addUnsigned(F(b, c, d), x), ac));
      return addUnsigned(rotateLeft(a, s), b);
    }

    function GG(a, b, c, d, x, s, ac) {
      a = addUnsigned(a, addUnsigned(addUnsigned(G(b, c, d), x), ac));
      return addUnsigned(rotateLeft(a, s), b);
    }

    function HH(a, b, c, d, x, s, ac) {
      a = addUnsigned(a, addUnsigned(addUnsigned(H(b, c, d), x), ac));
      return addUnsigned(rotateLeft(a, s), b);
    }

    function II(a, b, c, d, x, s, ac) {
      a = addUnsigned(a, addUnsigned(addUnsigned(I(b, c, d), x), ac));
      return addUnsigned(rotateLeft(a, s), b);
    }

    function convertToWordArray(string) {
      let lWordCount;
      const lMessageLength = string.length;
      const lNumberOfWordsTemp1 = lMessageLength + 8;
      const lNumberOfWordsTemp2 = (lNumberOfWordsTemp1 - (lNumberOfWordsTemp1 % 64)) / 64;
      const lNumberOfWords = (lNumberOfWordsTemp2 + 1) * 16;
      const lWordArray = Array(lNumberOfWords - 1);
      let lBytePosition = 0;
      let lByteCount = 0;

      while (lByteCount < lMessageLength) {
        lWordCount = (lByteCount - (lByteCount % 4)) / 4;
        lBytePosition = (lByteCount % 4) * 8;
        lWordArray[lWordCount] = (lWordArray[lWordCount] | (string.charCodeAt(lByteCount) << lBytePosition));
        lByteCount++;
      }

      lWordCount = (lByteCount - (lByteCount % 4)) / 4;
      lBytePosition = (lByteCount % 4) * 8;
      lWordArray[lWordCount] = lWordArray[lWordCount] | (0x80 << lBytePosition);
      lWordArray[lNumberOfWords - 2] = lMessageLength << 3;
      lWordArray[lNumberOfWords - 1] = lMessageLength >>> 29;

      return lWordArray;
    }

    function wordToHex(lValue) {
      let WordToHexValue = "", WordToHexValueTemp = "", lByte, lCount;

      for (lCount = 0; lCount <= 3; lCount++) {
        lByte = (lValue >>> (lCount * 8)) & 255;
        WordToHexValueTemp = "0" + lByte.toString(16);
        WordToHexValue = WordToHexValue + WordToHexValueTemp.substr(WordToHexValueTemp.length - 2, 2);
      }

      return WordToHexValue;
    }

    let x = [], k, AA, BB, CC, DD, a, b, c, d;
    const S11 = 7, S12 = 12, S13 = 17, S14 = 22;
    const S21 = 5, S22 = 9, S23 = 14, S24 = 20;
    const S31 = 4, S32 = 11, S33 = 16, S34 = 23;
    const S41 = 6, S42 = 10, S43 = 15, S44 = 21;

    string = unescape(encodeURIComponent(string));
    x = convertToWordArray(string);

    a = 0x67452301; b = 0xEFCDAB89; c = 0x98BADCFE; d = 0x10325476;

    for (k = 0; k < x.length; k += 16) {
      AA = a; BB = b; CC = c; DD = d;
      a = FF(a, b, c, d, x[k + 0], S11, 0xD76AA478);
      d = FF(d, a, b, c, x[k + 1], S12, 0xE8C7B756);
      c = FF(c, d, a, b, x[k + 2], S13, 0x242070DB);
      b = FF(b, c, d, a, x[k + 3], S14, 0xC1BDCEEE);
      a = FF(a, b, c, d, x[k + 4], S11, 0xF57C0FAF);
      d = FF(d, a, b, c, x[k + 5], S12, 0x4787C62A);
      c = FF(c, d, a, b, x[k + 6], S13, 0xA8304613);
      b = FF(b, c, d, a, x[k + 7], S14, 0xFD469501);
      a = FF(a, b, c, d, x[k + 8], S11, 0x698098D8);
      d = FF(d, a, b, c, x[k + 9], S12, 0x8B44F7AF);
      c = FF(c, d, a, b, x[k + 10], S13, 0xFFFF5BB1);
      b = FF(b, c, d, a, x[k + 11], S14, 0x895CD7BE);
      a = FF(a, b, c, d, x[k + 12], S11, 0x6B901122);
      d = FF(d, a, b, c, x[k + 13], S12, 0xFD987193);
      c = FF(c, d, a, b, x[k + 14], S13, 0xA679438E);
      b = FF(b, c, d, a, x[k + 15], S14, 0x49B40821);
      a = GG(a, b, c, d, x[k + 1], S21, 0xF61E2562);
      d = GG(d, a, b, c, x[k + 6], S22, 0xC040B340);
      c = GG(c, d, a, b, x[k + 11], S23, 0x265E5A51);
      b = GG(b, c, d, a, x[k + 0], S24, 0xE9B6C7AA);
      a = GG(a, b, c, d, x[k + 5], S21, 0xD62F105D);
      d = GG(d, a, b, c, x[k + 10], S22, 0x2441453);
      c = GG(c, d, a, b, x[k + 15], S23, 0xD8A1E681);
      b = GG(b, c, d, a, x[k + 4], S24, 0xE7D3FBC8);
      a = GG(a, b, c, d, x[k + 9], S21, 0x21E1CDE6);
      d = GG(d, a, b, c, x[k + 14], S22, 0xC33707D6);
      c = GG(c, d, a, b, x[k + 3], S23, 0xF4D50D87);
      b = GG(b, c, d, a, x[k + 8], S24, 0x455A14ED);
      a = GG(a, b, c, d, x[k + 13], S21, 0xA9E3E905);
      d = GG(d, a, b, c, x[k + 2], S22, 0xFCEFA3F8);
      c = GG(c, d, a, b, x[k + 7], S23, 0x676F02D9);
      b = GG(b, c, d, a, x[k + 12], S24, 0x8D2A4C8A);
      a = HH(a, b, c, d, x[k + 5], S31, 0xFFFA3942);
      d = HH(d, a, b, c, x[k + 8], S32, 0x8771F681);
      c = HH(c, d, a, b, x[k + 11], S33, 0x6D9D6122);
      b = HH(b, c, d, a, x[k + 14], S34, 0xFDE5380C);
      a = HH(a, b, c, d, x[k + 1], S31, 0xA4BEEA44);
      d = HH(d, a, b, c, x[k + 4], S32, 0x4BDECFA9);
      c = HH(c, d, a, b, x[k + 7], S33, 0xF6BB4B60);
      b = HH(b, c, d, a, x[k + 10], S34, 0xBEBFBC70);
      a = HH(a, b, c, d, x[k + 13], S31, 0x289B7EC6);
      d = HH(d, a, b, c, x[k + 0], S32, 0xEAA127FA);
      c = HH(c, d, a, b, x[k + 3], S33, 0xD4EF3085);
      b = HH(b, c, d, a, x[k + 6], S34, 0x4881D05);
      a = HH(a, b, c, d, x[k + 9], S31, 0xD9D4D039);
      d = HH(d, a, b, c, x[k + 12], S32, 0xE6DB99E5);
      c = HH(c, d, a, b, x[k + 15], S33, 0x1FA27CF8);
      b = HH(b, c, d, a, x[k + 2], S34, 0xC4AC5665);
      a = II(a, b, c, d, x[k + 0], S41, 0xF4292244);
      d = II(d, a, b, c, x[k + 7], S42, 0x432AFF97);
      c = II(c, d, a, b, x[k + 14], S43, 0xAB9423A7);
      b = II(b, c, d, a, x[k + 5], S44, 0xFC93A039);
      a = II(a, b, c, d, x[k + 12], S41, 0x655B59C3);
      d = II(d, a, b, c, x[k + 3], S42, 0x8F0CCC92);
      c = II(c, d, a, b, x[k + 10], S43, 0xFFEFF47D);
      b = II(b, c, d, a, x[k + 1], S44, 0x85845DD1);
      a = II(a, b, c, d, x[k + 8], S41, 0x6FA87E4F);
      d = II(d, a, b, c, x[k + 15], S42, 0xFE2CE6E0);
      c = II(c, d, a, b, x[k + 6], S43, 0xA3014314);
      b = II(b, c, d, a, x[k + 13], S44, 0x4E0811A1);
      a = II(a, b, c, d, x[k + 4], S41, 0xF7537E82);
      d = II(d, a, b, c, x[k + 11], S42, 0xBD3AF235);
      c = II(c, d, a, b, x[k + 2], S43, 0x2AD7D2BB);
      b = II(b, c, d, a, x[k + 9], S44, 0xEB86D391);
      a = addUnsigned(a, AA);
      b = addUnsigned(b, BB);
      c = addUnsigned(c, CC);
      d = addUnsigned(d, DD);
    }

    const temp = wordToHex(a) + wordToHex(b) + wordToHex(c) + wordToHex(d);
    return temp.toLowerCase();
  }

  // 接口调用方法（保持不变）
  async executeRequest() {
    let baseInfo = wfform.getBaseInfo() // 获取流程基础信息（包含workflowid、jdid等）
    const { jdid, lc, operator = '329' } = this.props; // 从props获取动态参数
    const url = "http://ip:port/api/cube/restful/interface/getDataByPK/getWorkflowNodeMsg";
    const now = new Date();
    const currentDate = now.toISOString().split('T')[0];
    const currentTime = now.toTimeString().substr(0, 8);
    const year = now.getFullYear();
    const month = String(now.getMonth() + 1).padStart(2, '0');
    const day = String(now.getDate()).padStart(2, '0');
    const hours = String(now.getHours()).padStart(2, '0');
    const minutes = String(now.getMinutes()).padStart(2, '0');
    const seconds = String(now.getSeconds()).padStart(2, '0');
    const currentTimestamp = `${year}${month}${day}${hours}${minutes}${seconds}`;

    // 系统标识和密码
    const systemid = "xxx";//建模的
    const d_password = "xxx";//建模的

    // 准备header参数
    const md5Source = systemid + d_password + currentTimestamp;
    const md5Str = this.md5(md5Source); // 使用组件内的md5方法

    const header = {
      "systemid": systemid,
      "currentDateTime": currentTimestamp,
      "Md5": md5Str.toLowerCase()
    };

    // 准备请求数据（使用props传递的动态参数）
    const paramDatajson = {
      "header": header,
      "pageInfo": {
        "pageNo": 1,
        "pageSize": 10
      },
      "mainTable": {
        "jdid": baseInfo.nodeid, // 动态获取
        "lc": baseInfo.workflowid,    // 动态获取
      },
      "operationinfo": {
        "operator": operator // 动态获取
      }
    };
    console.log(lc);
    console.log("===请求参数datajson===", paramDatajson);

    try {
      // 准备表单数据
      const formData = new URLSearchParams();
      formData.append('datajson', JSON.stringify(paramDatajson));

      // 发送POST请求
      const response = await fetch(url, {
        method: 'POST',
        headers: {
          'Content-Type': 'application/x-www-form-urlencoded; charset=utf-8'
        },
        body: formData
      });

      if (response.ok) {
        // 处理返回信息
        const res = await response.text();
        console.log("请求成功", res);
        // 假设返回的是JSON字符串，解析后存入state
        const resData = JSON.parse(res);
        this.setState({
          data: resData,
          loading: false,
          error: null
        });
      } else {
        const errorMsg = `获取数据失败，HTTP状态码: ${response.status}`;
        console.error(errorMsg, currentDate, currentTime);
        this.setState({
          error: errorMsg,
          loading: false
        });
      }
    } catch (error) {
      const errorMsg = "请求失败: " + error.message;
      console.error(errorMsg, currentDate, currentTime);
      this.setState({
        error: errorMsg,
        loading: false
      });
    }
  }

render() {
  const { visible, loading, error, data } = this.state;

  // 动态渲染内容
  let contentNode;
  if (loading) {
    contentNode = <div style={{ padding: '20px' }}>加载中...</div>;
  } else if (error) {
    contentNode = <div style={{ padding: '20px', color: 'red' }}>错误：{error}</div>;
  } else if (data) {
    // 解析嵌套的JSON结构以获取spnr值（兼容写法）
    let spnrValue = null;
    let parseError = null;

    try {
      // 第一层：解析result字段（它是一个JSON字符串）
      const resultObj = JSON.parse(data.result || '{}');

      // 第二层：从解析后的对象中获取spnr（使用传统判断方式，不依赖可选链）
      if (resultObj && resultObj.mainTable && resultObj.mainTable.spnr) {
        spnrValue = resultObj.mainTable.spnr;
      }
    } catch (e) {
      parseError = `数据解析错误: ${e.message}`;
      console.error(parseError);
    }

    // 根据解析结果展示内容
    contentNode = (
      <div style={{ padding: '15px', lineHeight: '1.6' }}>
        {parseError ? (
          <div style={{ color: 'red' }}>{parseError}</div>
        ) : spnrValue ? (
          // 展示spnr值并保留换行格式
          <div dangerouslySetInnerHTML={{ __html: spnrValue.replace(/\n/g, '<br>') }} />
        ) : (
          <div style={{ color: '#666' }}>未配置节点审批要求</div>
        )}
      </div>
    );
  } else {
    contentNode = <div style={{ padding: '20px' }}>暂无数据</div>;
  }

  return (
    <div>
      <WeaSlideModal
        visible={visible}
        top={12}
        width={20}
        height={20}
        direction={'right'}
        measure={'%'}
        title={'当前节点审阅要求'}
        content={contentNode}
        onClose={() => this.setState({ visible: false })}
        onAnimationEnd={() => console.log('onAnimationEnd')}
      />
    </div>
  );
}
}

ecodeSDK.setCom('${appId}', 'WfCustomInfoCopy', WfCustomInfoCopy);

发布看看效果：
