vlan 20
#
vlan 30
#
policy-based-route pb1 permit node 10
 if-match acl 2020
 apply next-hop 172.16.11.254
#
policy-based-route pb1 permit node 20
 if-match acl 2030
 apply next-hop 172.16.30.254
#
policy-based-route pb1 permit node 30


interface Vlan-interface20
 ip address 192.168.20.1 255.255.255.0
 ip policy-based-route pb1
#
interface Vlan-interface30
 ip address 192.168.30.1 255.255.255.0
 ip policy-based-route pb1


interface GigabitEthernet0/0
 port link-mode route
 combo enable copper
 ip address 172.16.11.9 255.255.255.0
 nat outbound
#
interface GigabitEthernet0/1
 port link-mode route
 combo enable copper
 ip address 172.16.30.9 255.255.255.0
 nat outbound
interface GigabitEthernet6/0
 port link-mode bridge
 port access vlan 20
 combo enable copper
#
interface GigabitEthernet6/1
 port link-mode bridge
 port access vlan 30
 combo enable copper


acl number 2020
 rule 0 permit source 192.168.20.0 0.0.0.255
 rule 5 deny
#
acl number 2030
 rule 0 permit source 192.168.30.0 0.0.0.255
 rule 5 deny
