罗技F710手柄描述符数据抓包 - 以及stm32读取usb-hid数据程序

绍磊leo

6396人浏览 · 2020-01-28 22:14:06

绍磊leo · 2020-01-28 22:14:06 发布

硬件： 罗技F710游戏手柄、一台笔记本电脑
软件： USBlyzer分析仪（下载地址）

大家都知道，罗技F710上有D模式和X模式，D模式是普通模式，每帧数据传输8个字节；X模式是xbox手柄模式，有更多的信息，每帧传输15个字节（因为有陀螺仪数据）。

D模式

先看8个字节的通讯协议：
以下是抓包内容，各种描述符分类清晰，在stm32的usb驱动程序中可以按照命名轻易找到对应的接口来修改。

Connection Status	Device connected
Current Configuration	1
Speed	Full (12 Mbit/s)
Device Address	14
Number Of Open Pipes	2

Device Descriptor Logitech Cordless RumblePad 2

Offset	Field	Size	Value	Description
0	bLength	1	12h
1	bDescriptorType	1	01h	Device
2	bcdUSB	2	0200h	USB Spec 2.0
4	bDeviceClass	1	00h	Class info in Ifc Descriptors
5	bDeviceSubClass	1	00h
6	bDeviceProtocol	1	00h
7	bMaxPacketSize0	1	08h	8 bytes
8	idVendor	2	046Dh	Logitech, Inc.
10	idProduct	2	C219h
12	bcdDevice	2	0305h	3.05
14	iManufacturer	1	01h	“Logitech”
15	iProduct	1	02h	“Logitech Cordless RumblePad 2”
16	iSerialNumber	1	00h
17	bNumConfigurations	1	01h

Configuration Descriptor 1 Bus Powered, 98 mA

Offset	Field	Size	Value	Description
0	bLength	1	09h
1	bDescriptorType	1	02h	Configuration
2	wTotalLength	2	0029h
4	bNumInterfaces	1	01h
5	bConfigurationValue	1	01h
6	iConfiguration	1	04h	“PACER-X03.05_A”
7	bmAttributes	1	80h	Bus Powered
	4…0: Reserved		…00000
	5: Remote Wakeup		…0…	No
	6: Self Powered		.0…	No, Bus Powered
	7: Reserved (set to one)(bus-powered for 1.0)		1…
8	bMaxPower	1	31h	98 mA

Interface Descriptor 0/0 HID, 2 Endpoints

Offset	Field	Size	Value	Description
0	bLength	1	09h
1	bDescriptorType	1	04h	Interface
2	bInterfaceNumber	1	00h
3	bAlternateSetting	1	00h
4	bNumEndpoints	1	02h
5	bInterfaceClass	1	03h	HID
6	bInterfaceSubClass	1	00h
7	bInterfaceProtocol	1	00h
8	iInterface	1	00h

HID Descriptor

Offset	Field	Size	Value	Description
0	bLength	1	09h
1	bDescriptorType	1	21h	HID
2	bcdHID	2	0111h	1.11
4	bCountryCode	1	00h
5	bNumDescriptors	1	01h
6	bDescriptorType	1	22h	Report
7	wDescriptorLength	2	0077h	119 bytes

Endpoint Descriptor 81 1 In, Interrupt, 4 ms

Offset	Field	Size	Value	Description
0	bLength	1	07h
1	bDescriptorType	1	05h	Endpoint
2	bEndpointAddress	1	81h	1 In
3	bmAttributes	1	03h	Interrupt
	1…0: Transfer Type		…11	Interrupt
	7…2: Reserved		000000…
4	wMaxPacketSize	2	0020h	32 bytes
6	bInterval	1	04h	4 ms

Endpoint Descriptor 01 1 Out, Interrupt, 8 ms

Offset	Field	Size	Value	Description
0	bLength	1	07h
1	bDescriptorType	1	05h	Endpoint
2	bEndpointAddress	1	01h	1 Out
3	bmAttributes	1	03h	Interrupt
	1…0: Transfer Type		…11	Interrupt
	7…2: Reserved		000000…
4	wMaxPacketSize	2	0020h	32 bytes
6	bInterval	1	08h	8 ms

Interface 0 HID Report Descriptor Game Pad

结合通讯协议，以及报告描述符，可以轻易写joystick驱动代码（用stm32的usb主机模式，读取usb-hid类设备驱动程序即可）

Item Tag (Value)	Raw Data
Usage Page (Generic Desktop)	05 01
Usage (Game Pad)	09 05
Collection (Application)	A1 01
Collection (Logical)	A1 02
Report ID (1)	85 01
Report Size (8)	75 08
Report Count (4)	95 04
Logical Minimum (0)	15 00
Logical Maximum (255)	26 FF 00
Physical Minimum (0)	35 00
Physical Maximum (255)	46 FF 00
Usage (X)	09 30
Usage (Y)	09 31
Usage (Z)	09 32
Usage (Rz)	09 35
Input (Data,Var,Abs,NWrp,Lin,Pref,NNul,Bit)	81 02
Report Size (4)	75 04
Report Count (1)	95 01
Logical Maximum (7)	25 07
Physical Maximum (315)	46 3B 01
Unit (Eng Rot: Degree)	66 14 00
Usage (Hat Switch)	09 39
Input (Data,Var,Abs,NWrp,Lin,Pref,Null,Bit)	81 42
Unit (None)	66 00 00
Report Size (1)	75 01
Report Count (12)	95 0C
Logical Maximum (1)	25 01
Physical Maximum (1)	45 01
Usage Page (Button)	05 09
Usage Minimum (Button 1)	19 01
Usage Maximum (Button 12)	29 0C
Input (Data,Var,Abs,NWrp,Lin,Pref,NNul,Bit)	81 02
Report Count (1)	95 01
Report Size (8)	75 08
Usage Page (Vendor-Defined 1)	06 00 FF
Logical Maximum (255)	26 FF 00
Physical Maximum (255)	46 FF 00
Usage (Undefined)	09 00
Input (Data,Var,Abs,NWrp,Lin,Pref,NNul,Bit)	81 02
End Collection	C0
Collection (Logical)	A1 02
Report ID (2)	85 02
Report Count (7)	95 07
Report Size (8)	75 08
Logical Maximum (255)	26 FF 00
Physical Maximum (255)	46 FF 00
Usage Page (Vendor-Defined 1)	06 00 FF
Usage (Vendor-Defined 3)	09 03
Input (Data,Var,Abs,NWrp,Lin,Pref,NNul,Bit)	81 02
End Collection	C0
Collection (Logical)	A1 02
Report ID (3)	85 03
Usage (Vendor-Defined 4)	09 04
Output (Data,Var,Abs,NWrp,Lin,Pref,NNul,NVol,Bit)	91 02
End Collection	C0
End Collection	C0

X模式

协议解析：

字节	0	1	2	3	4	5	6,7	8,9	10,11	12,13	14
定义	ID	0x14	Buttons	Buttons	LT	RT	Left X Axis	Left Y Axis	Right X Axis	Right Y Axis	Mode

Connection Status	Device connected
Current Configuration	1
Speed	Full (12 Mbit/s)
Device Address	15
Number Of Open Pipes	2

Device Descriptor Wireless Gamepad F710

Offset	Field	Size	Value	Description
0	bLength	1	12h
1	bDescriptorType	1	01h	Device
2	bcdUSB	2	0200h	USB Spec 2.0
4	bDeviceClass	1	FFh	Vendor-Specific
5	bDeviceSubClass	1	FFh
6	bDeviceProtocol	1	FFh
7	bMaxPacketSize0	1	08h	8 bytes
8	idVendor	2	046Dh	Logitech, Inc.
10	idProduct	2	C21Fh
12	bcdDevice	2	0305h	3.05
14	iManufacturer	1	01h	“Logitech”
15	iProduct	1	02h	“Wireless Gamepad F710”
16	iSerialNumber	1	03h	“8F699F3C”
17	bNumConfigurations	1	01h

Configuration Descriptor 1 Bus Powered, 98 mA

Offset	Field	Size	Value	Description
0	bLength	1	09h
1	bDescriptorType	1	02h	Configuration
2	wTotalLength	2	0030h
4	bNumInterfaces	1	01h
5	bConfigurationValue	1	01h
6	iConfiguration	1	00h
7	bmAttributes	1	80h	Bus Powered
	4…0: Reserved		…00000
	5: Remote Wakeup		…0…	No
	6: Self Powered		.0…	No, Bus Powered
	7: Reserved (set to one)(bus-powered for 1.0)		1…
8	bMaxPower	1	31h	98 mA

Interface Descriptor 0/0 Vendor-Specific, 2 Endpoints

Offset	Field	Size	Value	Description
0	bLength	1	09h
1	bDescriptorType	1	04h	Interface
2	bInterfaceNumber	1	00h
3	bAlternateSetting	1	00h
4	bNumEndpoints	1	02h
5	bInterfaceClass	1	FFh	Vendor-Specific
6	bInterfaceSubClass	1	5Dh
7	bInterfaceProtocol	1	01h
8	iInterface	1	00h

Unrecognized Class-Specific Descriptor

Offset	Field	Size	Value
0	bLength	1	10h
1	bDescriptorType	1	21h
2		14	10 01 01 24 81 14 03 00 03 13 02 00 03 00

Endpoint Descriptor 81 1 In, Interrupt, 4 ms

Offset	Field	Size	Value	Description
0	bLength	1	07h
1	bDescriptorType	1	05h	Endpoint
2	bEndpointAddress	1	81h	1 In
3	bmAttributes	1	03h	Interrupt
	1…0: Transfer Type		…11	Interrupt
	7…2: Reserved		000000…
4	wMaxPacketSize	2	0020h	32 bytes
6	bInterval	1	04h	4 ms

Endpoint Descriptor 02 2 Out, Interrupt, 8 ms

Offset	Field	Size	Value	Description
0	bLength	1	07h
1	bDescriptorType	1	05h	Endpoint
2	bEndpointAddress	1	02h	2 Out
3	bmAttributes	1	03h	Interrupt
	1…0: Transfer Type		…11	Interrupt
	7…2: Reserved		000000…
4	wMaxPacketSize	2	0020h	32 bytes
6	bInterval	1	08h	8 ms

手柄完整的数据协议：https://blog.csdn.net/liudijiang/article/details/86693435#Logitech_Wireless_Gamepad_F710_2

程序

顺便放一个我的程序，裸机读取usb手柄数据并发给串口，基于stm32h743，使用意法半导体官方IDEstm32cubeide生成并修改了部分驱动内容。

蓝奏云：https://www.lanzoui.com/i8wf6de

PS: 后续有时间更新一下生成和修改的过程，并移植到freertos中（官方ide直接生成的freertos + usb-host代码有bug，会直接内存泄露）。
