route1:

policy-based-route SanHaoLou permit node 20
 if-match acl 3001
 apply next-hop 1.1.1.2
#
interface Route-Aggregation1
 ip address 192.168.2.100 255.255.255.0
 ip policy-based-route SanHaoLou

interface GigabitEthernet0/0
 port link-mode route
 combo enable copper
 ip address 1.1.1.1 255.255.255.0
#
interface GigabitEthernet0/1
 port link-mode route
 combo enable copper
 port link-aggregation group 1
#
interface GigabitEthernet0/2
 port link-mode route
 combo enable copper
 port link-aggregation group 1

 ip route-static 192.168.1.0 24 192.168.2.10
#
acl advanced 3001
 rule 20 permit ip source 192.168.0.0 0.0.255.255


route2:

interface GigabitEthernet0/0
 port link-mode route
 combo enable copper
 ip address 1.1.1.2 255.255.255.0
--------------------------

ip route-static 0.0.0.0 0 1.1.1.1


switch:

vlan 100
#
 stp global enable
#
interface Route-Aggregation1
 ip address 192.168.2.10 255.255.255.0
#
interface NULL0
#
interface Vlan-interface100
 ip address 192.168.1.1 255.255.255.0

interface GigabitEthernet1/0/1
 port link-mode route
 combo enable fiber
 port link-aggregation group 1
#
interface GigabitEthernet1/0/2
 port link-mode route
 combo enable fiber
 port link-aggregation group 1


interface GigabitEthernet1/0/3
 port link-mode bridge
 port access vlan 100
 combo enable fiber
#

 ip route-static 0.0.0.0 0 192.168.2.100
学习篇供参考
