一 接入交换机igmp-snooping二层组播配置

#

igmp-snooping  //igmp-snooping配置

#

vlan 100

 igmp-snooping enable

 igmp-snooping drop-unknown

#

interface Ten-GigabitEthernet1/0/51

 port link-type trunk

 undo port trunk permit vlan 1

 port trunk permit vlan 100 to 101

 igmp-snooping static-router-port vlan 100

#

二 汇聚交换机网关igmp-snooping二层组播和PIM SM三层组播配置

 sysname ZhouJie

#

igmp-snooping   //igmp-snooping配置

#

vlan 100

 igmp-snooping enable

 igmp-snooping drop-unknown

#

vlan 101

 igmp-snooping enable

#

vlan 102

 description LJD

 igmp-snooping enable

 igmp-snooping drop-unknown

 igmp-snooping querier

#

multicast routing  //三层组播配置

#

pim  //pim rp配置

 c-rp 30.88.100.254 group-policy 2000

#

igmp

#

interface Vlan-interface100  //pim sm配置

 ip address 30.88.100.254 255.255.255.0

 pim sm

 igmp enable

#

interface Vlan-interface101

 ip address 30.88.101.254 255.255.255.0

#

interface Vlan-interface102

 ip address 30.88.102.254 255.255.255.0

 pim sm

 igmp enable

#

interface Vlan-interface1000

 ip address 40.1.1.30 255.255.255.252

 pim sm

 igmp enable

#
