[sw1]vlan batch 2 to 6

[sw1-GigabitEthernet0/0/1]port link-type access

 [sw1-GigabitEthernet0/0/1]port default vlan 2
[sw1-GigabitEthernet0/0/2]port link-type hybrid

[sw1-GigabitEthernet0/0/2]port hybrid pvid vlan 3

[sw1-GigabitEthernet0/0/2]port hybrid untagged vlan 3 4 5 6

[sw1-GigabitEthernet0/0/3]port link-type trunk

[sw1-GigabitEthernet0/0/3]port trunk allow-pass vlan 2 to 6

[sw1-GigabitEthernet0/0/4]port link-type hybrid

[sw1-GigabitEthernet0/0/4]port hybrid untagged vlan 3 4 5 6

[sw1-GigabitEthernet0/0/4]port hybrid tagged vlan 2

[sw2]vlan batch 2 to 6

[sw2-GigabitEthernet0/0/3]port link-type trunk

[sw2-GigabitEthernet0/0/3]port trunk allow-pass vlan 2 to 6

[sw2-GigabitEthernet0/0/1]port link-type access

[sw2-GigabitEthernet0/0/1]port default vlan 2

[sw2-GigabitEthernet0/0/2]port link-type hybrid

 [sw2-GigabitEthernet0/0/2]port hybrid pvid vlan 4

[sw2-GigabitEthernet0/0/2]port hybrid untagged vlan 3 4 5 6

[sw2-GigabitEthernet0/0/4]port link-type trunk

 [sw2-GigabitEthernet0/0/4]port trunk allow-pass vlan 2 to 6

[sw3]vlan batch 2 to 6

[sw3-GigabitEthernet0/0/3]port link-type trunk

 [sw3-GigabitEthernet0/0/3]port trunk allow-pass vlan 2 to 6

[sw3-GigabitEthernet0/0/1]port link-type hybrid

[sw3-GigabitEthernet0/0/1]port hybrid pvid vlan 5

[sw3-GigabitEthernet0/0/1]port hybrid untagged vlan 3 4 5

 [sw3-GigabitEthernet0/0/2]port link-type hybrid

[sw3-GigabitEthernet0/0/2]port hybrid pvid vlan 6

[sw3-GigabitEthernet0/0/2]port hybrid untagged vlan 3 4 6 2、

配置IP地址

 [r1-GigabitEthernet0/0/0]ip add 192.168.1.254 24

   [r1-GigabitEthernet0/0/0.1]dot1q termination vid 2

[r1-GigabitEthernet0/0/0.1]ip add 192.168.2.254 24

 [r1-GigabitEthernet0/0/0.1]arp  broadcast enable

 dhcp动态分配pc端ip地址：

 [r1]dhcp enable

 [r1-ip-pool-aa]network 192.168.1.0 mask 24

[r1-ip-pool-aa]gateway-list 192.168.1.254

[r1-ip-pool-aa]dns-list 8.8.8.8

 [r1-ip-pool-bb]network 192.168.2.0 mask 24

 [r1-ip-pool-bb]gateway-list 192.168.2.254

 [r1-ip-pool-bb]dns-list 8.8.8.8

 [r1-GigabitEthernet0/0/0]dhcp select   global

 [r1-GigabitEthernet0/0/0.1]dhcp select global
