RO：

dis cur
#
version 7.1.064, Release 0427P22
#
sysname RT4
#
system-working-mode standard
xbar load-single
password-recovery enable
lpu-type f-series
#
vlan 1
#
interface Serial1/0
#
interface Serial2/0
#
interface Serial3/0
#
interface Serial4/0
#
interface NULL0
#
interface GigabitEthernet0/0
port link-mode route
combo enable copper
ip address 10.1.1.4 255.255.255.0
#
interface GigabitEthernet0/1
port link-mode route
combo enable copper
ip address 10.2.2.4 255.255.255.0
#
interface GigabitEthernet0/2
port link-mode route
combo enable copper
#
interface GigabitEthernet5/0
port link-mode route
combo enable copper
#
interface GigabitEthernet5/1
port link-mode route
combo enable copper
#
interface GigabitEthernet6/0
port link-mode route
combo enable copper
#
interface GigabitEthernet6/1
port link-mode route
combo enable copper
#
scheduler logfile size 16
#
line class aux
user-role network-operator
#
line class console
user-role network-admin
#
line class tty
user-role network-operator
#
line class vty
user-role network-operator
#
line aux 0
user-role network-operator
#
line con 0
user-role network-admin
#
line vty 0 63
user-role network-operator
#
ip route-static 192.168.0.0 16 10.1.1.1
ip route-static 192.168.0.0 16 10.2.2.2

SW 1：

<SW1>dis cur
#
version 7.1.075, Alpha 7571
#
sysname SW1
#
irf mac-address persistent timer
irf auto-update enable
undo irf link-delay
irf member 1 priority 1
#
track 1 interface GigabitEthernet1/0/2
#
track 2 interface GigabitEthernet1/0/1
#
lldp global enable
#
system-working-mode standard
xbar load-single
password-recovery enable
lpu-type f-series
#
vlan 1
#
vlan 10
#
vlan 20
#
vlan 100
#
stp global enable
#
interface NULL0
#
interface Vlan-interface10
ip address 192.168.1.252 255.255.255.0
vrrp vrid 10 virtual-ip 192.168.1.254
vrrp vrid 10 priority 120
vrrp vrid 10 track 1 priority reduced 30
vrrp vrid 10 track 2 priority reduced 30
#
interface Vlan-interface20
ip address 192.168.2.252 255.255.255.0
vrrp vrid 20 virtual-ip 192.168.2.254
#
interface Vlan-interface100
ip address 10.1.1.1 255.255.255.0
#
interface FortyGigE1/0/53
port link-mode bridge
#
interface FortyGigE1/0/54
port link-mode bridge
#
interface GigabitEthernet1/0/1
port link-mode bridge
port link-type trunk
port trunk permit vlan 1 10 20
combo enable fiber
#
interface GigabitEthernet1/0/2
port link-mode bridge
port access vlan 100
combo enable fiber
#
interface GigabitEthernet1/0/3
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/4
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/5
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/6
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/7
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/8
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/9
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/10
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/11
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/12
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/13
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/14
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/15
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/16
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/17
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/18
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/19
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/20
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/21
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/22
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/23
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/24
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/25
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/26
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/27
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/28
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/29
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/30
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/31
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/32
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/33
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/34
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/35
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/36
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/37
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/38
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/39
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/40
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/41
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/42
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/43
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/44
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/45
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/46
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/47
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/48
port link-mode bridge
combo enable fiber
#
interface M-GigabitEthernet0/0/0
#
interface Ten-GigabitEthernet1/0/49
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/50
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/51
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/52
port link-mode bridge
combo enable fiber
#
scheduler logfile size 16
#
line class aux
user-role network-operator
#
line class console
user-role network-admin
#
line class tty
user-role network-operator
#
line class vty
user-role network-operator
#
line aux 0
user-role network-operator
#
line con 0
user-role network-admin
#
line vty 0 63
user-role network-operator
#
ip route-static 0.0.0.0 0 10.1.1.4

SW2:

<SW2>dis cur
#
version 7.1.075, Alpha 7571
#
sysname SW2
#
irf mac-address persistent timer
irf auto-update enable
undo irf link-delay
irf member 1 priority 1
#
track 1 interface GigabitEthernet1/0/2
#
track 2 interface GigabitEthernet1/0/2
#
lldp global enable
#
system-working-mode standard
xbar load-single
password-recovery enable
lpu-type f-series
#
vlan 1
#
vlan 10
#
vlan 20
#
vlan 200
#
stp global enable
#
interface NULL0
#
interface Vlan-interface10
ip address 192.168.1.253 255.255.255.0
vrrp vrid 10 virtual-ip 192.168.1.254
#
interface Vlan-interface20
ip address 192.168.2.253 255.255.255.0
vrrp vrid 20 virtual-ip 192.168.2.254
vrrp vrid 20 priority 120
vrrp vrid 20 track 1 priority reduced 30
vrrp vrid 20 track 2 priority reduced 30
#
interface Vlan-interface200
ip address 10.2.2.2 255.255.255.0
#
interface FortyGigE1/0/53
port link-mode bridge
#
interface FortyGigE1/0/54
port link-mode bridge
#
interface GigabitEthernet1/0/1
port link-mode bridge
port link-type trunk
port trunk permit vlan 1 10 20
combo enable fiber
#
interface GigabitEthernet1/0/2
port link-mode bridge
port access vlan 200
combo enable fiber
#
interface GigabitEthernet1/0/3
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/4
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/5
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/6
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/7
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/8
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/9
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/10
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/11
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/12
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/13
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/14
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/15
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/16
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/17
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/18
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/19
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/20
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/21
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/22
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/23
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/24
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/25
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/26
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/27
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/28
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/29
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/30
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/31
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/32
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/33
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/34
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/35
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/36
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/37
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/38
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/39
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/40
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/41
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/42
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/43
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/44
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/45
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/46
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/47
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/48
port link-mode bridge
combo enable fiber
#
interface M-GigabitEthernet0/0/0
#
interface Ten-GigabitEthernet1/0/49
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/50
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/51
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/52
port link-mode bridge
combo enable fiber
#
scheduler logfile size 16
#
line class aux
user-role network-operator
#
line class console
user-role network-admin
#
line class tty
user-role network-operator
#
line class vty
user-role network-operator
#
line aux 0
user-role network-operator
#
line con 0
user-role network-admin
#
line vty 0 63
user-role network-operator
#
ip route-static 0.0.0.0 0 10.2.2.4

Sw3:

<SW3>dis cur
#
version 7.1.075, Alpha 7571
#
sysname SW3
#
irf mac-address persistent timer
irf auto-update enable
undo irf link-delay
irf member 1 priority 1
#
lldp global enable
#
system-working-mode standard
xbar load-single
password-recovery enable
lpu-type f-series
#
vlan 1
#
vlan 10
#
vlan 20
#
stp global enable
#
interface NULL0
#
interface FortyGigE1/0/53
port link-mode bridge
#
interface FortyGigE1/0/54
port link-mode bridge
#
interface GigabitEthernet1/0/1
port link-mode bridge
port access vlan 10
combo enable fiber
#
interface GigabitEthernet1/0/2
port link-mode bridge
port access vlan 20
combo enable fiber
#
interface GigabitEthernet1/0/3
port link-mode bridge
port link-type trunk
port trunk permit vlan 1 10 20
combo enable fiber
#
interface GigabitEthernet1/0/4
port link-mode bridge
port link-type trunk
port trunk permit vlan 1 10 20
combo enable fiber
#
interface GigabitEthernet1/0/5
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/6
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/7
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/8
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/9
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/10
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/11
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/12
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/13
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/14
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/15
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/16
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/17
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/18
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/19
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/20
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/21
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/22
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/23
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/24
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/25
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/26
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/27
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/28
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/29
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/30
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/31
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/32
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/33
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/34
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/35
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/36
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/37
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/38
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/39
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/40
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/41
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/42
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/43
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/44
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/45
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/46
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/47
port link-mode bridge
combo enable fiber
#
interface GigabitEthernet1/0/48
port link-mode bridge
combo enable fiber
#
interface M-GigabitEthernet0/0/0
#
interface Ten-GigabitEthernet1/0/49
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/50
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/51
port link-mode bridge
combo enable fiber
#
interface Ten-GigabitEthernet1/0/52
port link-mode bridge
combo enable fiber
#
scheduler logfile size 16
#
line class aux
user-role network-operator
#
line class console
user-role network-admin
#
line class tty
user-role network-operator
#
line class vty
user-role network-operator
#
line aux 0
user-role network-operator
#
line con 0
user-role network-admin
#
line vty 0 63
user-role network-operator
#
radius scheme system
user-name-format without-domain
#
domain name system
#
domain default enable system
#
role name level-0
description Predefined level-0 role
#
role name level-1
description Predefined level-1 role
#
role name level-2
description Predefined level-2 role
#
role name level-3
description Predefined level-3 role
#
role name level-4
description Predefined level-4 role
#
role name level-5
description Predefined level-5 role
#
role name level-6
description Predefined level-6 role
#
role name level-7
description Predefined level-7 role
#
role name level-8
description Predefined level-8 role
#
role name level-9
description Predefined level-9 role
#
role name level-10
description Predefined level-10 role
#
role name level-11
description Predefined level-11 role
#
role name level-12
description Predefined level-12 role
#
role name level-13
description Predefined level-13 role
#
role name level-14
description Predefined level-14 role
#
user-group system
#
return

https://blog.csdn.net/2201_75532230/article/details/152209430,通到route

DAMO开发者矩阵

DAMO开发者矩阵，由阿里巴巴达摩院和中国互联网协会联合发起，致力于探讨最前沿的技术趋势与应用成果，搭建高质量的交流与分享平台，推动技术创新与产业应用链接，围绕“人工智能与新型计算”构建开放共享的开发者生态。

更多推荐

从埋点到画像：政策平台的用户行为数据 pipeline

DAMO开发者矩阵

D3SL 系列安全门锁内部逃生解锁装置实操案例具备内部逃生功能的工业安全门互锁开关实拍 D3SL 系列安全门锁防人员误锁困：带逃生解锁安全门锁应用案例立宏安全

DAMO开发者矩阵

聊天机器人和智能体之间，隔着什么？

企业AI落地的核心难题，不是"有没有AI"，而是"AI能不能真正融入业务流程"。聊天机器人可以在业务流程之外提供辅助，但无法深入其中。真正的智能体平台——像JBoltAI这样的企业级平台——让AI具备执行多步骤任务、调取企业数据、连接业务系统的能力，从而真正成为业务流程的一部分。山东向量空间认为，这是企业AI建设从"聊天"到"干活"的关键跨越。JBoltAI要做的，就是让每家企业都能实现这个跨越。
