Computes the Total Harmonic Distortion (THD) of a signal

function [ THD, ph, amp ] = compute_THD( t,x, freq )

Written by Dr. Yoash Levron

February 2013.

Computes the Total-Harmonic-Distortion (THD)

of a signal x(t). The amplitude and phase of the basic harmonic are also computed. These values are typically useful in power systems, audio signal processing, and other related fields.

The function computes the basic harmonic

of the signal, in the form:

x(t) = amp*cos(w*t - ph) + (higher Harmonics)

where : w = 2*pi*freq

so 'amp' and 'ph' are the phase and amplitude

of the basic harmonic.

DC offset does not affect THD.

inputs:

t - [sec] time vector. (should be periodical with basic harmonic 'freq')

x - signal vector.

freq - [Hz] frequency of the basic harmonic.

outputs:

THD - total harmonic distortion (the scale is 1 = 100%).

ph - [rad] phase of the basic harmonic.

amp - Amplitude of the basic harmonic.
